Электроподжиг на 6 свечей WAC-6A для плиты Ariston/Аристон, GAZ008

 Ariston, фото 1  Ariston, фото 2
Проверить совместимость
P 40 GE5.1 PX 40 GE5.1 P 40G E6.1(B) MX 40 G5 SPX 40 G5 SPX 41 G5 SX 40 G5 SX 4P GE5 G 940 G6(W) G640G6(W) G1 MTD(W) G3 VTD(X) G2 VTD (W) SGX 4C G5.2 EG SKD SG 4C G5.2 EG SKD G 940 G6.2(W) G3 VTD (X) NG PF7 60MS (IX) PF7 60MS (WH) PF7 60MS (TF) PF7 60MS (BK) G1 MTD.E (W) G3 VTD.E (X) G2 VTD.E (W) G 84C G5 (X)T SKD PA 950 MSD PF7 60MS (OG) PF7 60MS (OS) PF7 60MS (PK) G2 VTD (W) R G3 VTD (X) R PF7 60MS (PA) PF7 60MS (AN) PF7 60MS (OW) PF7 60MS (GW) PH 960MST (IX) (T) PH 960MST (WH) PH 960MST (AN) PH 960MST (OS) PH 960MST (OW) PH 960MST (OG) PH 960MST (GW/PB) G 640 G7S (W) G 640 G7S (X) G1 MD10 (X) G 740 G6S (X) G 740 G6S (W) G 94D E5 (X) G 640 G7 (W) PF7 60MS (PB) PF7 60MS (PG) PRO 94 DG (X) PRO 84 G (X) PF7 60MS (AV) G 94D G5 (X) G 84C G5 (X)T SKD.1 PH 960MT (IX) NG PF7 60MS U (WH) PF7 60MS U (AN) PF7 60MS U (IX) PH 960MST U (IX) PRO 94 DG (X) UK PF7 60MS (IX) NG PRO 94 DM (X) UK XP 90 G.1 C 659 B X.1 C 647 G (X) C 659 P X.1 T 753 S (AN) T 753 S (WH) T 753 S (IX) T 750 S (AN) T 750 S (WH) T 750 S (IX) T 753 S (AN)EXP T 753 S (IX)EXP T 750 S (AN)EXP T 750 S (IX)EXP C 648 B X C 647 G (W) PF7 60MS U (OW) PX951/A IX/CL ST50 PX951/A TF/CL ST53 PX951/A IX/BL ST51 PX951/A NE/BL PX951/A CF/BL ST74 PX951/A BC/BC ST57 PX951/A IX/IX ST55 PX940P/A IX PX940DC/A IX PX940DC/AS IX PX930PDC/A IX PX930PDC/AS IX FL 940DC/A IX FL 940DC/AS IX FL 940P/A IX FL 940P/AS IX FLA 940DC/AS IX FLA 940P/AS IX EU951/A IX EU951/A MK EU951/A NE EU951/A BC EU951/A CF EU951/A TF EU951/A BG EU951/AS IX EU951/AS MK EU951/AS NE EU951/AS BC EU951/AS CF EU951/AS TF EU951/AS BG EU940P/A IX EU940P/A BC EU940P/A TF EU940P/AS IX EU940P/AS MK EU940P/AS BC EU940P/AS TF EU940TC/A IX EU940TC/A MK EU940TC/A BC EU940TC/A TF EU940TC/AS IX EU940TC/AS MK EU940TC/AS BC EU940TC/AS TF EU930PTC/A IX EU930PTC/A MK EU930PTC/A BC EU930PTC/A TF EU930PTC/AS IX EU930PTC/AS MK EU930PTC/AS BC EU930PTC/AS TF P95TC/PF IX CRF C CTA 940DC/AS BLU C CTA 940DC/AS AVO C CTA 940DC/AS IX C 658 P (X)T C 649 B (W)T C 645 G (W)F C 647 G (W)F C 647 BT (W)F C 6471 G A F C 659 P X F G 94D G6 (W) G 960 G6 (W) XM 180 GS.1 XM 180 GD.1 G 94D G4S (W)CKD KG 9504PD XG/S CKD PH 960 MST(IX)NG C 647 G A R C 647 G (W)R KGM 9505 XGS/I KP 9507 XE/O XC 95 M C 447 G (X) C 057 G (X) C 955 ED (X) PF 750 AST (IX) PF 750 AST (AX) PF 750 AST (WH) PF 750 AST (OW) PF 750 AST (AN) PF 750 AST GH PF 750 AST (OS) PF 750 AST (AV) PF 750 ASP (IX) PF 750 ASP (AX) PF 750 ASP (TF) PF 760 AS (IX) PF 760 AS (AX) PF 760 AS (WH) PF 760 AS (TF) PF 760 AS (OW) PF 760 AS (AN) PF 760 AS GH PF 760 AS (AV) PF 760 AS (PK).1 C 659 B X AG.1 C 645 G (X)AG.1 C 057 GP (W)F C 057 GP (X)F C 645 G (W)EX C 645 G (W)T SKD C 659 P X NG(1) C 055 GD (X) EX C 065 G (W) EX C 955 GD (X) EX C 954 GD (W) EX C 965 G (W) EX C 647 G (W)B C 659 B X B CTA 9040TC/AS CRF PH 960MST (AX) PH 960MST (AV) PH 960MST (PA) KG 9605 WG/S C 659 B X C 659 P X C 645 G (W)AG.1 K 642 G(W)/G K 642 GS(X)/R C 055 GD (X) SKD C 055 GD (X)T SKD C 947 GD (W) CKD KGM 9506 WG/S.2 KGM 9506 XG/S.2 C 058 MT (X).1 BM 9040TC/AS BM 21040TC/AS(SX) BM 21040TC/AS(DX) K 645 GSX/I K 645 GS(W)/I C 065 G (X) EX C 645 G (C)T SKD(1) P 950 A (IX) P 950 A (TF) P 950 AS (IX) K 642 G(W)/F(1) K 642 GS(X)/G PF 760 AS XX PF 760 AS (BK) PF 760 AS (OS) PF 760 AS (OG) PF 760 AS (GW/PB) PF 760 AS (PA) PF 750 AST XX PF 750 AST (BK) PF 750 AST (TF) PF 750 AST (OG) PF 750 AST(GW/PB) PF 750 AST (PA) PF 750 ASP (AN) PF 750 ASP (WH) KP 9507 XE/B PFP 9040TC/AS BNV0 PFP 6030TC/AS BNV0 PIP 6030TC/AS BNV0 PIP 9040TC/AS BNV0 K 647 GS(X)/G BP 9040TC/AS BP 21040TC/AS (DX) BP 21040TC/AS (SX) C 758 MT (X)/I C 757 GT (X)/I C 858 MT (X)/I C 857 GT (X)/I XC 95 MG (IX) XC 95 MG (IX) NL(1) XC 95 MG (AN) XC 95 MG (AN) NL(1) C 647 G (X)EU XP 90 GH.1 PFP 9040TC/AS PIP 9040TC/AS K 345 GS(X)/U PH 960MST GH (T) K 345 GS(XW)/U K 345 G(W)/U CP 965 G CE K 962 G(W)/S K 962D G(X)/S CKD K 952D G(W)/S CKD K 642 G(XW)/AG.1 EST K 642 G (XW)(1) FUN K 642 G (XW) K 642 G(X)/AG.1 EST K 642 G (X)(1) FUN K 642 G (X)(1) C 058 MT (XA) C 758 MT (XA)/I CTA 9040TC/AS IX K 642R GS(X)/G PRO 95 GT.01 (T) PF 750 AS (IX) PF 750 AS (AX) PF 750 AS (WH) PF 750 AS (TF) BB402TC(2400-Q) 2V KP 9507 XE/G KM 52D G(W)/EX KM 52D G(X)/EX KM 52D GS(X)/I K 642 G(W)/F TLE 75S AN FRA TLE 75S AN EXP TLE 75S IX FRA TLE 75S IX EXP KP 59 MS(X)/G PF 760 DR GH (IX) PF 760 DR GH (AN) PF 760 DR GH (AV) C 345 G (W)F C 67 GT (X) C 645 G (C)T SKD C 659 P X NG XC 95 MG (IX) NL XC 95 MG (AN) NL KP 958 MS(X)/O C 344 G (W)P C 345 G (X)P C 345 G (W)P C 347 G (W)P C 347 G (X)P CPS 9040TC/AS IX K 643 G(X)/G CP 059 MT(X) UK XBC 902 GH DC XC 902 GH DC TP 96 G CE C 659 P X UK XP 90 G XP 90 GH XM 210 GS XM 210 GD XM 180 GS XM 180 GD XC 902 GH DC NL TP 95 G PP 93 G BP 215 GD BP 215 GS CP 955 G PP 63 G KP 958 MS(X)/D PRO 94 DG (X) UK.1 PF 750 AST (AX)IR CP 647 GT (T) CP 757 GT CP 857 GT (T) CP 859 MT CP 057 GT (T) CP 058 MT CP 059 MT CP 649 MD CP 059 MD Annullato2 K 645 G(W)/G K 645 G(X)/G K 645R G(X)/G K 647R G(X)/G C 645 G (W)ALG PF 750 AST (PK) K 6432 G (X)/G C 647 G(W) EX K 962 G(WH)/S K 942 G(XS)/I C 954 GD (WH) EX C 955 ED (XS) C 955 GD (XS) EX C 648 GT (W) F G750TX G760FX G760DX GF960X GX901X PP 63 G NL PP 93 G NL TP 95 G NL BP 215 GD NL BP 215 GS NL CP 955 G NL CP 058 GT (X) F (T) CP 059 MD.3(X) F (T) XC 902 GH DC AUS C 658 P.3 (X)T XC 902 GH DC.3 (T) XC 902 GH DC.3 NL(T) CP 649 MD.2 CP 859 MT.2 (T) CP 059 MT.2 (T) CP 058 MT.2 (T) PH 960MST (BK) CP 059 MD.2(X) NL(T) CP 649 MD.2 (X)NL(T) KP 958 MS.B(X)/D (T) PP 93 G AT CP 955.3 G CP 955.3 G NL KP 9507 E.B(X)/G KP 9507 E.B(X)/O (T) KP 958 MS.B(X)/O (T) C 659 P.4 X I CP 059 MD.2 (T) C 659 P.4 X F C 346 GT (W)F EG900X (T) K 942 GS(XS)/I K 955 MS.C(XS)/I C 346 GT (X)F KP 59 MS.C(X)/G (T) S860GX T 753 S/M (AN) T 753 S/M (WH) T 753 S/M (IX) T 753 S/M (IX)EXP CP 058 MT.2 B CP 649 MD (X) AUS(T) CP 059 MD (X) AUS(T) CP 859 MT(X) AUS (T) C 65 G1 (W) F CP 759 FT C 67S P2 X I C 66S P6 (X) I C 64S G1 (X) I C 64S G1 (W) I CP 059 MD (X) DE C 64S G1 (W) B C 64S G3 (B) R C 64S G1 X EX C 64S G3 (X) R C 64S G3 (W) R C 64S G1 (W) EX K6G2(W)/F K6G21S(W)/R K6G21S(X)/R B 40TC DX 2V BFB KP 958 MS (X)/DK (T) 10460G C 66S P6 (X) NL C 66S P6 (W) NL C 66S P6 (A) U K6G21(W)/CF PF 750 AST (AN) R PF 750 AST (OW) R PH 960 MST (AN) R PH 960 MST (OW) R P 750 AS (IX) P 750 AST (IX) K6G25S(W)/U K6G21(X)/G K6G21(W)/G CP 08S P6 DK K3G21S(X)/U K3G21S(W)/U PI 750 AS (IX) PI 750 AST (IX) B 40TC AR DX 1V5 VC B 40TC AR SX 1V5 VC PI 950 A (IX) CP 756 G (T) PF 750 AST (AV) R PF 750 AST (OS) R PF 750 AST (PA) R PF 750 AST (GW/PB) R PH 960MST (AV) R PH 960MST (OS) R GC750TX CJ 32G W CP 956 G (T) B 40TC/CS 1050 RB BQ 40DCDR AR CP 98S P1 (X) F (T) PFP 9040TC/AS BNV BB 40TC 15 B 40DCDR AR 1 BP 40TC/CS BNV 17 BQ 40DCDR ERN 1 KP 9508 E(X)/G (T) BP 40TC AR 16 PI 950 AST (IX) EX B 40TC 76 B 402TC 6 CP 98S P6 (X) F (T) CP 756 G (FR) CP 647 GT CP 649 MD (X) AUS CP 649 MD.2 (X) NL CP 757 GT (IT) CP 758 MT.1 CP 08S P6 AN (T) KP 59 MS.C(X)/G XBM 211 GH TC D/HA XBM 211 GH TC S/HA XBC 902 GH DC/HA XBC 901 GH TC/HA BQ 40DCDR/CS 31 BP 40TC AR 70 PI 950 AS (IX) BLC LAV  2987 SOM37A4S0N SOM34A2S0N PZF 950 T GH N /HA BQ 40DCDR/CS 244
Купить в магазине
г. Краснодар, ул. Гаврилова, 85
Или заказать с доставкой
Характеристики
Бренд Ariston
Артикул
  • 031720
  • 033969
  • 030956
  • 581002000
  • 581001501
Страна Китай
Надпись - Маркировка WAC-6A
Материал Металл / Пластик
Гарантия 6 месяцев
Код GAZ008
Описание
Блок розжига искры на 6 свечей для плиты.

3 контакта питания: "N" , "L".
Выход: на 6 шт. свечей розжига: на верх на газ.конфорки - 4 шт. +  2 шт. в духовку для верхней и нижней горелки.
Надписи на блоке: (могут отличаться) Javatech или GP group.
Размеры: расстояние между центрами крепежного отверстия: 123 мм.
Характеристики: 220/240V, 50/60Hz, 0.6 VA, T=120°C ROHS

ВОЗМОЖНЫ ВАРИАНТЫ ЗАМЕНЫ 2-Х КОНТАКТОВ ПИТАНИЯ "N" И "L" ВМЕСТО 3-Х. "N" , "L" и "масса (земля)"

Устройство подачи искры для газовой плиты на 6 выводов устанавливается на модели газовых плит и газовых варочных поверхностей:
ARDO
Ariston
Indesit
Kaiser
Hansa
Gorenje
Electrolux
Candy
Bosch
Blomberg
Whirpool
Zanussi
ВЕКО
